| Key Attributes | |
|---|---|
| Mounting Type | Bolt Mounting |
| Manufacturing Date Code | 2025 |
| Model Number | FGS-31N |
| Brand Name | FUWEI |
| Usage | Color identification |
| Description | Precise Color Recognition, Color sensor |
| Type | FIBER OPTIC SENSOR |
| Series | FGS-31N |
| Features | FGS-31N |
| Place of Origin | Guangdong, China |
| Theory | Photoelectric Detection Principle |
| Output | NPN/PNP |
| Description | sensor |
| Spot size | 1*5mm (setting distance: 10mm) |
| Consumption current | <30mA |
| Ambient humidity | 35~88RH |
| International Protection | IP67 (IEC) |
| Detection range | 10±3mm |
| Supply voltage | 12~24V DC |
| Response time | Color scale/color mode |
| Ambient temperature | -10℃~55℃ |
| Light source | Red/Green/Blue LED |
| Selling Units | Single item |
| Single package size | 10X10X4 cm |
| Single gross weight | 0.500 kg |
